46140 CNC Solid Carbide Compression Spiral Single Flute 1/4 Dia x 7/8 x 1/4 Inch Shank

$99.31

Usually ships on the 2nd business day from order date.
D-diameter 1/4
B-cutting-height 7/8
B1 3/8
D-shank 1/4
Overall-length-l 2-1/2
Type Solid Carbide
Flutes 1
You will receive a courtesy discount of 5% if your cart exceeds $100 :)

Description

Special unique carbide for longer lifetime in abrasive material. Designed for CNC applications requiring high feed rates and a clean finish. Particularly suitable for double-sided melamine or laminated material.

  • Laminate
  • Laminated Plywood
  • Melamine
  • Melamine Particle Board
  • MDF/HDF
  • Oriented Strand Board (OSB)*
  • Particle Board
  • Softwood/Hardwood
  • Veneered Plywood

*Oriented Strand Board is an engineered wood particle board.

Recommended RPM 20,000-21,000.

Specifications

(D) Diameter 1/4
(B) Cutting Height 7/8
B1 3/8
(d) Shank 1/4
Overall Length (L) 2-1/2
Type Solid Carbide
Flutes 1
