48200 Carbide Tipped Plastic Trim Saw Blade and Arbor CNC System 4 Inch Dia x 20T TCG, 0 Deg x 1/2 Shank 100% Flash Mounting
$271.80
Usually ships on the 2nd business day from order date.
| Diameter-d | 4 |
|---|---|
| Shank-d | 1/2 |
| Overall-length-l | 3-1/4 |
| Max-rpm | 13,000 |
| C | 1-1/8 |
| Feed-rate-ipm | 150" |
| Grind | TCG |
| Teeth | 20 |
| Hook-angle | 0º |
| Kerf-b | .095" (3/32) |
Description
Designed for trimming and grooving hard and soft plastics.
100% flash mounting.
Right hand rotation cutting.
Excellent for cutting:
- Hard & Soft Plastics
- Acrylonitrile Butadiene Styrene (ABS)
- Fomex®
- High Impact Polystyrene (HIPS)
- High Pressure Laminates (HPL)
- Hydroxy-Terminated Polyether (HTPE)
- Low Density Polyethylene (LDPE)
- LubX®
- Polyethylene Terephthalate Glycol-Modified (PETG / PET-G)
- Polyoxymethylene (POM), also known as Acetal, Polyacetal and Polyformaldehyde.
- Thermoplastic Polyolefin (TPO)
- Sign Foam
- StarBoard® (King StarBoard ‘R’) High Density Polyethylene Sheet (HDPE)
- Urethane
Specifications
| (D) Diameter | 4 |
| (d) Shank | 1/2 |
| Overall Length (L) | 3-1/4 |
| Max RPM | 13,000 |
| C | 1-1/8 |
| Feed Rate IPM | 150" |
| Grind | TCG |
| Teeth | 20 |
| Hook Angle | 0º |
| Kerf (B) | .095" (3/32) |
