DT300T48-30 Carbide Tipped Ditec 2000 Adjustable Type Scoring 300mm Dia x 48T ATB, 8 Deg, 30mm Bore, Scoring Set

$239.19

Diameter (D) 300mm
Teeth 48
(d) Bore 30mm
Tooth Grind CONICAL
Hook Angle
Kerf (B) .173 - .212 (4.4 - 5.4mm)
Machine Schelling
Plate (c) .126 (3.2mm)

Description

Used on panel saws with separate scoring units for chip-free cuts on both sides of the material. With conical type scoring blades, the kerf width changes with depth of penetration. Used in combination with our industrial saw blades ‘7’ series only (#714721, etc.). Also used in combination with the new DITEC™ series panel saw main blades. Kerf range should match the main blade.

Specifications

(D) Diameter 300mm
Teeth 48
(d) Bore 30mm
Tooth Grind CONICAL
Hook Angle
Kerf (B) .173 - .212 (4.4 - 5.4mm)
Machine Schelling
Plate (C) .126 (3.2mm)
