55293 Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop, 3/8 Dia x 7/64 Drill Dia x 1/4 Inch Quick Release Hex Shank
$45.78
(a°) Angle | 49° |
---|---|
(B) Cutting Height | 5/64-11/32 |
Diameter (D) | 3/8 |
Shank (d) | 1/4 |
Overall Length (L) | 2-3/8 |
Wood Screw Size | #4 |
D1 | 7/64 |
Replacement Drill | 630-224 |
Description
A must have tool for every woodworker!
Includes drill (slow spiral, High-Speed-Steel (HSS) M2 fully ground drill bit).
Low friction polymer collar. No surface scratches or burn marks!
These tools combine carbide countersink, high-speed-steel drill bit and free-spinning, low friction depth-stop. The countersink leaves a clean hole edge and the adjustable depth-stop doesn’t mar the surface. The large openings around the collar allow the chips to clear effectively and eliminate clogging.
Quick release 1/4″ hex shank with slow spiral, HSS M2 fully ground drill bit included.
Excellent for Drilling:
Natural Woods
Man-Made Boards
MDF
Chipboard
Plywood
Aluminum/Non-Ferrous
Aluminum Composite Material (ACM)
Composites
Composite Decking Materials
Warning: When drilling aluminum/non-ferrous materials, for optimal results and extended tool life use lubricant or air cooling. Make sure the material is fixed and drill is stable during drilling.
Specifications
(a°) Angle | 49° |
(B) Cutting Height | 5/64-11/32 |
Diameter (D) | 3/8 |
Shank (d) | 1/4 |
Overall Length (L) | 2-3/8 |
Wood Screw Size | #4 |
D1 | 7/64 |
Replacement Drill | 630-224 |
