610601-30 Carbide Tipped Heavy Duty General Purpose 10 Inch Dia x 60T TCG, 10 Deg, 30mm Bore

$131.55Flag Image

While this blade handles general trimming and crosscutting of hardwood and softwood, plywood and composition materials, it excels at cutting single or double-sided plastic-laminated material. It leaves a smooth, clean, chip-free finish on the top and bottom edges. The blades in this series feature a high tooth count, the triple-chip grind and a 10° hook angle for a successful compromise between feed effort and cut finish.

Diameter (D) 10mm
Teeth 60
(d) Bore 30mm
Tooth Grind TCG
Hook Angle 10°
Kerf (B) .126 (3.2mm)
Pinholes 2/7/42, 2/9/46 & 2/10/60
Plate (c) .087 (2.2mm)
UPC: 738685106303.0 SKU: 610601-30 Categories: , ,
You will receive a courtesy discount of 5% if your cart exceeds $100

Specifications

(D) Diameter 10 (250mm)
Teeth 60
(d) Bore 30
Tooth Grind TCG
Hook Angle 10°
Kerf (B) .126 (3.2mm)
Pinholes 2/7/42, 2/9/46 & 2/10/60
Plate (C) .087 (2.2mm)
