61366 Insert Carbide Adjustable Groove with Scorer 180mm (7-1/16) Dia x 12.5 to 24mm (1/2 to 15/16) x 1-1/4 Bore
$561.78
Usually ships on the 2nd business day from order date.
Diameter (D) | 180mm (7-1/16) |
---|---|
(d) Bore | 1-1/4 |
(B) Cutting Height | 12.5 to 24mm (1/2 to 15/16) |
Max T | 40mm (1-1/2) |
RPM | 4,300-7,500 |
Teeth | 4+4 |
Replacement Knives | AMA-19(4), RCK-70(4) |
Description
Hard wearing steel body complete with tungsten carbide knives and scorer for improved finish. Suitable for producing various thickness grooves and slots in softwood, hardwood and man-made boards (with or without coating) on a spindle molder. Cutting width can be adjusted in 0.1mm increments by special threaded bushing and scale without removing the cutter from the spindle.
Specifications
(D) Diameter | 180mm (7-1/16) |
(d) Bore | 1-1/4 |
(B) Cutting Height | 12.5 to 24mm (1/2 to 15/16) |
Max T | 40mm (1-1/2) |
RPM | 4,300-7,500 |
Teeth | 4+4 |
Replacement Knives | AMA-19(4), RCK-70(4) |
