220T640 Carbide Tipped Holz-Her General Purpose 220mm Dia x 64T ATB, 10 Deg, 30mm Bore

$203.83Flag Image

Designed specifically for the Holz-Her® 220mm panel saws. Our trim blade, suitable for use on table saws, sliding table saws, radial arms, and miter saws of all types, leaves a super-smooth finish when cutting hard or softwood. It is especially suited to trimming and sizing veneers and laminates, in single sheets or in stacks. The alternate top bevel grind and high tooth counts produce excellent, chip-free cuts. The 10° hook angle provides effortless feeding.

Diameter (D) 220mm
Teeth 64
(d) Bore 30mm
Tooth Grind ATB
Hook Angle 10°
Application Crosscut wood
Kerf (B) .118 (3.0mm)
Pinholes 2/7/42
Plate-c .079 (2.0mm)
UPC: 738685226407.0 SKU: 220T640 Categories: , ,
You will receive a courtesy discount of 5% if your cart exceeds $100

Specifications

(D) Diameter 220mm
Teeth 64
(d) Bore 30mm
Tooth Grind ATB
Hook Angle 10
Application Crosscut wood
Kerf (B) .118 (3.0mm)
Pinholes 2/7/42
Plate (C) .079 (2.0mm)
