56174 Carbide Tipped Plunge Beading 13/64 Radius x 7/8 Dia x 15/32 x 1/4 Inch Shank
$62.79
Usually ships on the 2nd business day from order date.
Diameter (D) | 7/8 |
---|---|
D1 | 1/2 |
Radius (R) | 13/64 |
(B) Cutting Height | 15/32 |
B1 | 1/4 |
Shank (d) | 1/4 |
Overall Length (L) | 2-3/16 |
Flutes | 2 |
Description
Quarter-round profiles are formed by this bit as it grooves, one on each side of a flat. Used with a fence or edge guide, this beading bit can be used as an edge former.
Maximum RPM 14,000.
Use in a table-mounted router. Not for use in a handheld router!
Specifications
Diameter (D) | 7/8 |
D1 | 1/2 |
Radius (R) | 13/64 |
Cutting Height (B) | 15/32 |
B1 | 1/4 |
Shank (d) | 1/4 |
Overall Length (L) | 2-3/16 |
Flutes | 2 |
