HG220T420 Carbide Tipped Hollow Ground 220mm Dia x 42T HG, -6 Deg, 30mm Bore
$198.14
Usually ships on the 2nd business day from order date.
| Diameter (D) | 220mm |
|---|---|
| Teeth | 42 |
| (d) Bore | 30mm |
| Tooth Grind | HG |
| Hook Angle | -6° |
| Application | Melamine |
| Kerf (B) | .126 (3.2mm) |
| Pinholes | 2/7/42 |
| Plate (c) | .087 (2.2mm) |
Description
This specially designed saw blade makes exceptionally smooth cuts in melamine and other coated boards, without the need for scoring. The unique hollow grind, which pairs a triple-chip tooth with a raker tooth that’s ground to a concave profile, produces crisp, clean cuts. The grind is commonly used in vertical panel saws, such as those made by Striebig® and Holz-Her®. The negative hook angle is particularly suitable for vertical panel saws.
Specifications
| (D) Diameter | 220mm |
| Teeth | 42 |
| (d) Bore | 30mm |
| Tooth Grind | HG |
| Hook Angle | -6° |
| Application | Melamine |
| Kerf (B) | .126 (3.2mm) |
| Pinholes | 2/7/42 |
| Plate (C) | .087 (2.2mm) |
